How to Add Resources and Scripts to a GTA Connected Server

To add a resource to a GTA Connected server, put its folder inside the server's resources folder, make sure the folder contains a valid meta.xml, then add <resource src="foldername" /> to the <resources> block in server.xml and restart. You can also start it without a restart by typing start foldername in the server console. A resource without a meta.xml, or one that is not listed in server.xml, never loads, and those two mistakes cause most "my script does nothing" questions.

Resources are how a GTAC server becomes anything other than plain freeroam: a deathmatch mode, a race system, a roleplay framework or a single admin command. This guide covers how they are built, how to install someone else's, and how to write a tiny one of your own.

What a resource is

A resource is a folder (or a tar archive) in resources/ that holds scripts and any files they need: images, audio, maps or extra data. Several resources can run at once and they can depend on each other. A typical layout:

resources/
  freeroam/
    meta.xml
    ...
  myadmin/
    meta.xml
    server.js
    client.js

The server ships with freeroam, which is why a fresh server already lets players spawn and drive around.

The meta.xml file

Every resource needs a meta.xml in its root. It tells the server what the resource is and which scripts to run where. The full set of node types from the official wiki:

<meta>
  <info author="" type="" version="" description="" />
  <script src="" type="" language="" />
  <dependency src="" />
  <map src="" type="" />
  <file src="" type="" />
</meta>

On a script node:

• src is the path to the file, relative to the resource folder.
• type is server for code that runs on the server, or client for code that downloads to and runs on each player's game.
• language is lua, javascript or squirrel. You can mix languages inside one resource.

Installing a resource someone else wrote

Community resources come from the GTA Connected forum and GitHub. The steps are the same for all of them:

1. Check the game. A resource written for GTA IV usually calls functions or models that do not exist in Vice City. Read its description first.
2. Upload the folder into resources/ with SFTP or your file manager. The folder name is the resource name, so keep it short with no spaces.
3. Open its meta.xml and confirm it is at the top of the folder, not one level down (a common result of unzipping a GitHub download, which creates resources/thing-main/thing/meta.xml).
4. Check dependencies. If meta.xml has dependency lines, those resources must also be in the folder.
5. Add it to server.xml:

<resources>
  <resource src="freeroam" />
  <resource src="myadmin" />
</resources>

6. Restart the server and read the console. A broken script prints its error and line number while the resource loads.

Starting, stopping and reloading without a restart

The server console accepts resource commands, so you can test changes while players stay connected:

Use these while developing. Once a resource works, make sure it is in server.xml, because anything started by hand is gone after the next server restart.

Writing a tiny resource

A minimal server side JavaScript resource. Create resources/hello/meta.xml:

<meta>
  <info author="you" type="script" version="1.0.0" description="Hello command" />
  <script src="server.js" type="server" language="javascript" />
</meta>

Then resources/hello/server.js:

addCommandHandler('hello', function(command, text, client)
{
    console.log(client.name + ' said hello');
});

Run start hello in the console, type /hello in game, and the line appears in the server console. On the server side, command handlers receive the command, the text after it and the client who typed it. The GTA Connected wiki lists every function and event per game.

How client files reach players

Client scripts and file entries download to players when they join. GTAC serves them through its built in HTTP server on httpport (22000 by default, TCP). If that port is blocked, players hang while downloading resources. For a busy server you can set httpurl in server.xml to a web host or CDN that holds the same files, which takes the load off the game server.

Script files themselves are sent over the game connection and are not cached on the player's side, so client code stays fresh after every change.

Common problems

If players cannot reach the server at all, that is a different problem: see our GTA Connected connection fix guide.

Doing this on a hosted server

On a GamezServers GTA Connected server, the resources folder and server.xml are in the file manager, and SFTP makes uploading a whole resource folder one drag. The live console accepts start, stop and restart, so you can test a script without kicking anyone, and both ports are already open, which removes the stuck download problem. Take a one click backup before you install a big roleplay framework, so you can roll back if it breaks your setup. New to GTAC? Start with our GTA Connected setup guide.

FAQ

Which scripting languages does GTA Connected support?

Lua, JavaScript and Squirrel. Set the language attribute on each script node in meta.xml.

Do I need to restart the server to add a resource?

No. Type start name in the console to run it right away. Add it to server.xml too, or it will not start after the next restart.

Where do client scripts go?

In the same resource folder, listed in meta.xml with type="client". Players download them when they join.

Can I use SA-MP Pawn scripts on GTA Connected?

No. GTAC resources are Lua, JavaScript or Squirrel. Pawn gamemodes need SA-MP or open.mp.
